Size Matters: This is a 16" fan. Unlike other electric fans, the size indicates the size of the blade not the assembly.

Reversible push/pull blades.
High quality, long life motors.
Thin, aerodynamic profile for applications
with limited space.
Full fingerguard shroud.
16" high performance.
Super Quiet hi-flow S-Blade Design.

Note: This item is shipped set-up as a pusher fan. To use as a puller fan, undo front retaining clip and turn over the fan blade assembly. Re-attach clip and wire with reverse polarity.		 .
16" HP Radiator Fan (12 Volt)
Following the success of our 24 volt High-Performance Radiator Fans we also offer this 12 volt 16" High-Performance radiator fan for owners of off-road vehicles with 12 volt electrical systems.

Electric fans are ideal for O.E. replacement, supplemental or add-on cooling needs. As a primary cooling source electric fans provide economical replacement for failed OE parts, with a 5-10% increase in horsepower and fuel mileage when replacing belt-driven fan assemblies. As an add-on cooling source electric fans provide increased air conditioning performance due to constant airflow across the condenser, with additional cooling in heavy traffic or while towing, or driving off-road.		 .
.
U.S. SHIPMENTS (CONTINENTAL U.S. ONLY)
16" HP Radiator Fan (12 Volt)
Shipping		 . $129.95
$19.00 *		 .
Total . $148.95 .
* Includes sales tax for shipments within Oklahoma .

(click image for large view)
 . .
.

PERFORMANCE DATA @ 13.5VDC
12 VOLT PUSHER FAN

AIRFLOW
DIRECTION

PERFORMANCE DATA @ 13.5VDC
12 VOLT PULLER FAN

Static Pressure Airflow Current
H20(in) H20(mm) CFM m3/h Amps
0.0 0.0 2320 3945 20.2
0.1 2.5 2090 3555 20.4
0.2 5.0 1960 3330 20.8
0.3 7.5 1815 3085 20.8
0.4 10.0 1650 2805 20.4
0.5 12.5 1430 2430 20.3
0.6 15.0 1100 1870 19.7
0.7 17.5 660 1120 19.1
Static Pressure Airflow Current
H20(in) H20(mm) CFM m3/h Amps
0.0 0.0 2320 3945 19.7
0.1 2.5 2090 3555 20.1
0.2 5.0 1960 3330 20.3
0.3 7.5 1815 3085 19.9
0.4 10.0 1595 2710 19.8
0.5 12.5 1210 2055 19.7
0.6 15.0 770 1310 19.4
0.7 17.5 550 935 19.2
. .
.

24 Volt Radiator Fans
Our 24 volt High-Performance Radiator Fans are designed for military or ex-military vehicles with 24 volt electrical systems.		 .

6 & 12 Circuit Fuse Blocks
Works excellently with our 24 & 12 volt electrical items. Allows you to run 6 or 12 individually fused 12 volt circuits.		 .

Battery Isolator Kit
Handles alternators up to 95 amps. Complete kit with mounting hardware and wiring. Charges one or both batteries.		 .
. .
